Product Overview
DS18 PRO-TWZ1S
3.8" Shallow-Mount Super Bullet Compression Tweeter With 1" Aluminum Voice Coil
With a reduced mounting depth of just 1.3", the PRO-TWZ1S delivers the same screaming highs in more places than ever.
Shred Through Any Mix
This 3.8" bullet tweeter delivers razor-sharp frequencies from 3.15kHz to 20kHz. Upgrade your front stage or build a competition-level wall, with a compression tweeter strong enough to lead any system.
Pure Aluminum Voice Coil + Diaphragm
Equipped with a 1” aluminum voice coil wound on a Kapton former and a matching aluminum diaphragm, the PRO-TWZ1S blends sharp responsiveness with durability.
Built-In Bass Blocker
A ferrite magnet core with a built-in 4.7uf bass blocker protects your highs and extends performance under pressure. You get full treble protection without adding a crossover.
Get highs anywhere with the PRO-TWZ1S shallow-mount tweeters built to hit harder, fit tighter, and scream louder.
Key Features
- Ultra-Shallow 1.3" Mounting Depth
- Razor-Sharp Highs (3.15kHz–20kHz)
- 1" Aluminum Voice Coil + Diaphragm
- Built-In 4.7µF Bass Blocker
- Competition-Ready SPL Output
Specifications
| Nominal Diameter | 3.8" / 96mm |
|---|---|
| Nominal Impedance | 4 Ohms |
| AES Power Handling | 50W |
| Program Power Handling | 100W |
| Peak Power Handling | 200W |
| Sensitivity (1w/1m) | 105 dB |
| Frequency Response | 3.15KHz-20kHz |
| Recommended High-Pass Crossover | 4kHz |
| Sold In Pair or Single | Pair |
| Filter (Bass Blocker) | 4.7uf |
| Body Material | Aluminum |
| Body Color / Finish | Black |
| Faceplate Color / Finish | Black / Machined |
| Bullet Material | Aluminum |
| Voice Coil Diameter | 1" / 25.4mm |
| Voice Coil Former Material | Kapton |
| Winding Material | CCAW |
| Diaphragm Material | Aluminum |
| Magnet Material | Ferrite |
| Magnet Weight | 6.5 Oz |
| Overall Diameter | 3.78" / 96mm |
| Overall Depth | 1.8" / 45.5mm |
| Front Mount Baffle Cutout | 2.83" / 72mm |
| Mounting Depth | 1.3" / 35mm |
| Motor Diameter | 2.76" / 70mm |
