Orion XTX 6x9 Midrange Speaker - 400 Watts RMS
Orion XTX 6x9 Midrange Speaker - 400 Watts RMS
Orion XTX 6x9 Midrange Speaker - 400 Watts RMS
Orion XTX 6x9 Midrange Speaker - 400 Watts RMS. Available manufacturer models: XTX6952 (2 Ohm), XTX6954 (4 Ohm). Select the impedance or configuration that matches your system; specifications for each model are listed below.
Manufacturer specifications
XTX6952 - 2 Ohm
- Speaker Size: 6 x 9 (Inches)
- Voice Coil Configuration: 2 ohm
- Power Handling (Peak): 1600 Watts
- Power Handling (RMS): 400 Watts
- Sensitivity: 94 dB
- Frequency Response: 140Hz - 12 kHz
- Voice Coil Diameter: 1.5" (Inches)
- Speaker Quantity: 2 Speakers
- Material: Cast Basket
- Cone Material: Non Pressed Paper
- Phase Plug Material: Billet Aluminum
- Magnet Information: 44 Oz. Ferrite
- Grilles Included: No
- Mounting Depth: 88.5mm
- Overall Depth: 98mm
- Overall Diameter: 244.63x173.13
- Mounting Diameter: 170.36x119.54
XTX6954 - 4 Ohm
- Speaker Size: 6 x 9 (Inches)
- Voice Coil Configuration: 4 ohm
- Power Handling (Peak): 1600 Watts
- Power Handling (RMS): 400 Watts
- Sensitivity: 94 dB
- Frequency Response: 140Hz - 12 kHz
- Voice Coil Diameter: 1.5" (Inches)
- Speaker Quantity: 2 Speakers
- Material: Cast Basket
- Cone Material: Non Pressed Paper
- Phase Plug Material: Billet Aluminum
- Magnet Information: 44 Oz. Ferrite
- Grilles Included: No
- Mounting Depth: 88.5mm
- Overall Depth: 98mm
- Overall Diameter: 244.63x173.13
- Mounting Diameter: 170.36x119.54
