Orion XTRPRO 8 Inch Competition Subwoofer - 1000 Watts RMS
Orion XTRPRO 8 Inch Competition Subwoofer - 1000 Watts RMS
Orion XTRPRO 8 Inch Competition Subwoofer - 1000 Watts RMS
Orion XTRPRO 8 Inch Competition Subwoofer - 1000 Watts RMS. Available manufacturer models: XTRPRO802D (Dual 2 Ohm), XTRPRO804D (Dual 4 Ohm). Select the impedance or configuration that matches your system; specifications for each model are listed below.
Manufacturer specifications
XTRPRO802D - Dual 2 Ohm
- Subwoofer Size: 8 (Inches)
- Voice Coil Configuration: Dual 2-ohm
- Power Handling (Peak): 4000 Watts
- Power Handling (RMS): 1000 Watts
- Sensitivity: 85.23 dB
- Frequency Response: 40 Hz - 150 Hz
- Voice Coil Diameter: 2.5 (Inches)
- Voice Coil Material: Aluminum Wound Voice Coil on a Kapton Former
- Spider: Dual Flat Conex Spiders with Loop Stitched Tinsel Leads
- Dustcap Material: Polypropylene
- Cone Material: UV Coated Reinforced Paper
- Surround Material: Santoprene
- Basket Material: Proprietary Cast Aluminum Frame
- Magnet Information: 125 Oz Ferrite
- Speaker Displacement: 0.06 (cu. ft.)
- Mounting Depth: 176.8mm / 6.96 (Inches)
- Cutout Diameter: 202.9mm / 7.99 (Inches)
XTRPRO804D - Dual 4 Ohm
- Subwoofer Size: 8 (Inches)
- Voice Coil Configuration: Dual 4-ohm
- Power Handling (Peak): 4000 Watts
- Power Handling (RMS): 1000 Watts
- Sensitivity: 84.75 dB
- Frequency Response: 40 Hz - 150 Hz
- Voice Coil Diameter: 2.5 (Inches)
- Voice Coil Material: Aluminum Wound Voice Coil on a Kapton Former
- Spider: Dual Flat Conex Spiders with Loop Stitched Tinsel Leads
- Dustcap Material: Polypropylene
- Cone Material: UV Coated Reinforced Paper
- Surround Material: Santoprene
- Basket Material: Proprietary Cast Aluminum Frame
- Magnet Information: 125 Oz Ferrite
- Speaker Displacement: 0.06 (cu. ft.)
- Mounting Depth: 176.8mm / 6.96 (Inches)
- Cutout Diameter: 202.9mm / 8.07 (Inches)
