Orion XTRPRO102D - 10 Inch Dual 2 Ohm Competition Subwoofer | 1250W RMS Bass Power

High-Performance 10 Inch Subwoofer Built for Extreme Output

The Orion XTRPRO102D is built for serious bass performance. Specifically, it is designed as a 10 inch dual 2 ohm competition car subwoofer . As a result, it delivers powerful and controlled low-frequency output. With 1250W RMS and 5000W peak power , it is made for high-output audio systems that demand strength and reliability.

Additionally, the dual 2-ohm voice coil design allows flexible wiring options. Because of this, it is easier to match amplifier loads in powerful systems. Therefore, the XTRPRO102D works well in competition builds, high-output daily drivers, and custom bass setups.

Built for Extreme Power Handling

To support high power levels, the XTRPRO102D uses a UV-coated reinforced paper cone . Moreover, it features a durable Santoprene surround . Together, these materials help control cone movement while keeping bass tight and accurate.

At its core, the subwoofer includes a 2.5-inch aluminum-wound voice coil on a Kapton former . As a result, heat control is improved during heavy use. In addition, dual flat Conex spiders with loop-stitched tinsel leads help keep the cone stable during hard movement.

A 133 oz ferrite magnet motor structure provides strong control and efficiency. Therefore, bass remains deep and powerful at higher output levels. The subwoofer is also built on a proprietary cast aluminum frame , which adds strength and helps improve cooling.

Ideal For

Manufacturer specifications

XTRPRO102D

• Subwoofer Size: 10 (Inches)
• Voice Coil Configuration: Dual 2-ohm
• Power Handling (Peak): 5000 Watts
• Power Handling (RMS): 1250 Watts
• Sensitivity: 87.8 dB
• Frequency Response: 35 Hz - 500 kHz
• Voice Coil Diameter: 2.5 (Inches)
• Voice Coil Material: Aluminum Wound Voice Coil on a Kapton Former
• Spider: Dual Flat Conex Spiders with Loop Stitched Tinsel Leads
• Dustcap Material: Polypropylene
• Cone Material: UV Coated Reinforced Paper
• Surround Material: Santoprene
• Basket Material: Proprietary Cast Aluminum Frame
• Magnet Information: 133 Oz Ferrite
• Speaker Displacement: 0.1204 (cu. ft.)
• Mounting Depth: 185mm / 7.27 (Inches)
• Cutout Diameter: 235mm / 9.25 (Inches)
• Overall Diameter: 271mm / 10.67 (Inches)
