Orion HCCA1052NHP 10 Inch 2 Ohm Midrange Speaker - 700W RMS / 2800W Peak. Select the correct impedance for your system. Orion's model specifications are listed below.
Manufacturer specifications
HCCA1052NHP - 2 Ohm
- Speaker Size: 10 (Inches)
- Voice Coil Configuration: 2 ohm
- Power Handling (Peak): 2800 Watts
- Power Handling (RMS): 700 Watts
- Sensitivity: 103.9 dB
- Frequency Response: 116 Hz - 5.5 kHz
- Voice Coil Diameter: 3" (Inches)
- Speaker Quantity: 1 Speaker
- Material: Cast Basket
- Cone Material: Non Pressed Paper
- Phase Plug Material: Billet Aluminum
- Magnet Information: Neodymium
- Grill Included: No
- Mounting Depth: 98mm / 3.86 (Inches)
- Overall Depth: 112mm / 4.41 (Inches)
- Cutout Diameter: 234mm / 9.21 (Inches)
- Overall Diameter: 265mm / 10.43 (Inches)
