Orion XTR15D4 - 15 Inch Dual 4 Ohm Car Subwoofer | 750W RMS Bass Power

High-Output 15 Inch Subwoofer with Flexible Wiring and Deep Bass

The Orion XTR15D4 delivers powerful low-frequency performance in a large, performance-focused design. Specifically engineered as a 15 inch dual 4 ohm car subwoofer, it produces deep bass with control and efficiency. As a result, it is ideal for high-output systems. With 750W RMS and 3000W peak power, it offers an excellent balance of output, durability, and long-term reliability.

Additionally, the dual 4-ohm voice coil configuration provides flexible wiring options. Because of this, matching amplifier loads becomes easier across different system layouts. Therefore, the XTR15D4 works well in daily-driven builds, high-output trunk systems, and multi-subwoofer configurations.

Built for Clean, Powerful Output

To ensure consistent performance, the XTR15D4 features a non-pressed paper cone. Moreover, it uses a durable foam surround to support controlled excursion. Together, these materials help deliver strong bass response while maintaining efficiency.

At its core, the subwoofer uses a 3-inch voice coil designed to handle higher power levels. As a result, thermal stability is improved during extended listening sessions. In addition, a ceramic magnet motor structure provides strong control and reliable output across the operating range.

Whether installed in a sealed enclosure for tighter response or a ported enclosure for maximum impact, this 15 inch dual 4 ohm car subwoofer delivers deep, authoritative bass that remains controlled.

Ideal For

• High-output trunk and cargo-area installations
• Daily-driven systems needing deep bass presence
• Multi-subwoofer setups using dual voice coils
• Performance-focused car audio builds

Key Features

• 15 inch dual 4 ohm car subwoofer
• 750W RMS / 3000W peak power handling
• Dual voice coil design for flexible wiring configurations
• Non-pressed paper cone for efficient bass response
• Foam surround for controlled excursion
• 3" high-power voice coil
• Ceramic magnet motor structure
• 7.36" mounting depth
• Optimized for sealed and ported enclosures
• Proven Orion Car Audio XTR Series build quality

Key Features

• Engineering Excellence: The Orion XTR15D4 subwoofer exemplifies engineering excellence with a peak power handling of 3000 Watts and RMS power handling of 1000 Watts.
• Dual 4-ohm Configuration: Featuring a dual 4 ohm voice coil setup, this subwoofer offers versatile wiring options for seamless integration into a wide range of audio setups.
• Superior Sound Reproduction: The UV-coated paper/fiber blend cone and Santoprene surround ensure precise sound reproduction, maintaining clarity even under high-power conditions.
• Efficient Sensitivity: With a sensitivity rating of 87.1 dB, this subwoofer efficiently converts power into impactful sound, delivering dynamic and detailed bass response.
• Extended Frequency Range: The subwoofer's frequency response spans from 20 Hz to 250 Hz, capturing both the deep rumble and intricate details of your music.
• Advanced Cooling System: Designed for reliability, the subwoofer features an advanced cooling system to prevent overheating and ensure consistent performance.
• Flexible Impedance: The dual 4-ohm impedance configuration ensures compatibility with a variety of amplifiers and audio systems, facilitating seamless integration.
• High-Quality Magnet: Equipped with a ceramic magnet structure, the subwoofer generates powerful magnetic fields, contributing to accurate and resonant bass reproduction.

Specifications

• Subwoofer Size: 15" (Inches)
• Voice Coil Configuration: Dual 4 ohm
• Power Handling (Peak): 3000 Watts
• Power Handling (RMS): 750 Watts
• Sensitivity: 87.1 dB
• Frequency Response: 20Hz -250 Hz
• Voice Coil Diameter: 3" (Inches)
• Cone Material: Non-Pressed Paper Cone
• Surround Material: Foam
• Mounting Depth: 7.36" (Inches)
• Cutout Diameter: 14.25" (Inches)
• Magnet Material: Ceramic
• Overall Diameter: 15.67" (Inches)
