Orion XTR12D2 - 12 Inch Dual 2 Ohm Car Subwoofer | 600W RMS Bass Power

High-Output 12 Inch Subwoofer with Deep, Controlled Bass Performance

The Orion XTR12D2 delivers powerful and accurate bass in a performance-driven design. Specifically engineered as a 12 inch dual 2 ohm car subwoofer, it produces deep low-frequency output while maintaining control and efficiency. As a result, it works well in demanding audio systems. With 600W RMS and 2400W peak power, it offers an excellent balance of output, durability, and long-term reliability.

Additionally, the dual 2-ohm voice coil configuration provides flexible wiring options. Because of this, matching amplifier loads becomes easier across different system layouts. Therefore, the XTR12D2 is well suited for daily-driven builds, high-output systems, and multi-subwoofer configurations.

Built for Clean, Powerful Output

To ensure consistent performance, the XTR12D2 features a UV-coated paper and fiber blend cone. Moreover, it uses a durable Santoprene surround to improve excursion control. Together, these materials help reduce distortion while maintaining accurate bass response.

A polypropylene dustcap reinforces the cone assembly. As a result, stability is maintained during higher output levels. In addition, a 55 oz ceramic magnet motor structure provides strong control and efficiency across the operating range.

Whether installed in a sealed enclosure for tight bass or a ported enclosure for added impact, this 12 inch dual 2 ohm car subwoofer delivers punchy, controlled low frequencies that remain clean and defined.

Ideal For

• Trunk-based custom installations
• High-output daily driving systems
• Multi-subwoofer setups using dual voice coils
• Performance-focused car audio builds

Key Features

• 12 inch dual 2 ohm car subwoofer
• 600W RMS / 2400W peak power handling
• Dual voice coil design for flexible wiring configurations
• UV-coated paper and fiber blend cone
• Santoprene surround for durability and control
• Polypropylene dustcap for added cone stability
• 55 oz ceramic magnet motor structure
• 6.22" mounting depth
• Optimized for sealed and ported enclosures
• Proven Orion Car Audio XTR Series build quality

Key Features

• Precision Engineering: The Orion XTR12D2 subwoofer offers uncompromising audio precision with a peak power handling of 2400 Watts and RMS power handling of 600 Watts.
• Dual 2-ohm Configuration: Featuring a dual 2 ohm voice coil setup, this subwoofer provides versatile wiring options for seamless integration into various audio setups.
• Superior Sound Reproduction: The UV-coated paper/fiber blend cone and Santoprene surround ensure faithful sound reproduction, maintaining clarity even under high-power conditions.
• Efficient Sensitivity: With a sensitivity rating of 87.38 dB, this subwoofer efficiently converts power into impactful sound, delivering dynamic and detailed bass response.
• Broad Frequency Range: The subwoofer's frequency response spans from 24 Hz to 250 Hz, capturing both the deep lows and intricate details of your audio content.
• Enhanced Cooling System: Designed for reliability, the subwoofer features an advanced cooling system to prevent overheating and ensure consistent performance.
• Flexible Impedance: The dual 2-ohm impedance configuration ensures compatibility with various amplifiers and audio systems, facilitating seamless integration.
• High-Quality Magnet: Equipped with a ceramic magnet structure, the subwoofer generates strong magnetic fields, contributing to accurate and resonant bass reproduction.

Specifications

• Subwoofer Size: 12" (Inches)
• Voice Coil Configuration: Dual 2-ohm
• Power Handling (Peak): 2400 Watts
• Power Handling (RMS): 600 Watts
• Sensitivity: 87.38 dB
• Frequency Response: 20 Hz - 250 Hz
• Voice Coil Diameter: 2 (Inches)
• Dustcap Material: Polypropylene
• Cone Material: UV Coated Paper / Fiber Blend Cone
• Surround Material: Santoprene
• Magnet Information: 55 Oz Ceramic
• Mounting Depth: 158mm / 6.22 (Inches)
• Cutout Diameter: 277mm / 10.91 (Inches)
• Overall Diameter: 319mm / 12.56 (Inches)
