Orion XTR10D4 - 10 Inch Dual 4 Ohm Car Subwoofer | 500W RMS Bass Power
High-Output 10 Inch Subwoofer with Flexible Wiring Options The Orion XTR10D4 delivers strong and controlled bass in...
- $139.95
- $139.95
- Unit price
- per
Subtotal:
$139.95
Couldn't load pickup availability
Out of stock
High-Output 10 Inch Subwoofer with Flexible Wiring Options
The Orion XTR10D4 delivers strong and controlled bass in a compact, performance-focused design. Specifically engineered as a 10 inch dual 4 ohm car subwoofer, it produces deep low-frequency output without requiring oversized enclosures. As a result, it fits easily into a wide range of system builds. With 500W RMS and 2000W peak power, it offers an excellent balance of output, efficiency, and long-term reliability.
Additionally, the dual 4-ohm voice coil configuration provides flexible wiring options. Because of this, matching amplifier loads becomes easier across different setups. Therefore, the XTR10D4 works well in daily-driven systems, compact SPL builds, and multi-subwoofer configurations.
Built for Clean, Controlled Output
To ensure consistent performance, the XTR10D4 features a UV-coated paper and fiber blend cone. Moreover, it uses a durable Santoprene surround for improved excursion control. Together, these materials help reduce distortion while maintaining accurate bass response.
A polypropylene dustcap reinforces the cone assembly. As a result, stability is maintained during higher output levels. In addition, a ceramic magnet motor structure provides reliable control and efficiency across the operating range.
Whether installed in a sealed enclosure for tight response or a ported enclosure for added impact, this 10 inch dual 4 ohm car subwoofer delivers punchy bass that remains clean and defined.
Ideal For
- Trunk-based and compact custom installations
- High-output daily driving systems
- Multi-subwoofer setups using dual voice coils
- Space-efficient performance builds
Key Features
- 10 inch dual 4 ohm car subwoofer
- 500W RMS / 2000W peak power handling
- Dual voice coil design for flexible wiring configurations
- UV-coated paper and fiber blend cone
- Santoprene surround for durability and control
- Polypropylene dustcap for added cone stability
- Ceramic magnet motor structure
- 5.31" mounting depth
- Optimized for sealed and ported enclosures
- Proven Orion Car Audio XTR Series build quality
Key Features
- Uncompromising Bass Power: The Orion XTR10D4 subwoofer delivers impactful bass with a peak power handling of 2000 Watts and RMS power handling of 500 Watts, ensuring an immersive audio experience.
- Dual 4 ohm Configuration: Featuring a dual 4 ohm voice coil setup, this subwoofer provides versatility in wiring options, allowing customization for various audio setups.
- Precision Construction: The UV-coated paper/fiber blend cone and Santoprene surround guarantee precise sound reproduction, preserving clarity even in challenging audio environments.
- Efficient Sensitivity: With a sensitivity rating of 84.65 dB, this subwoofer efficiently converts power into impactful sound, delivering dynamic and detailed bass response.
- Wide Frequency Range: The subwoofer's frequency response spans from 20 Hz to 500 Hz, capturing both the deep lows and finer nuances of your music.
- Advanced Cooling System: Engineered for reliability, the subwoofer includes an advanced cooling system to prevent overheating and ensure consistent performance.
- Flexible Impedance: The dual 4 ohm impedance configuration offers compatibility with a variety of amplifiers and audio setups, allowing seamless integration.
- High-Quality Magnet: Equipped with a ceramic magnet structure, the subwoofer generates strong magnetic fields, contributing to accurate and resonant bass reproduction.
Specifications
- Subwoofer Size: 10 (Inches)
- Voice Coil Configuration: Dual 4-ohm
- Power Handling (Peak): 2000 Watts
- Power Handling (RMS): 500 Watts
- Sensitivity: 84.65 dB
- Frequency Response: 20 Hz - 250 Hz
- Dustcap Material: Polypropylene
- Cone Material: UV Coated Paper / Fiber Blend Cone
- Surround Material: Santoprene
- Magnet Information: Ceramic
- Mounting Depth: 135mm / 5.31 (Inches)
- Cutout Diameter: 230mm / 9.10 (Inches)
- Overall Diameter: 271mm / 10.67 (Inches)
