HCCA2000.4 - 2000W RMS 4-Channel Class-AB Amplifier

ORION HCCA2000.4 HCCA Series 2000W RMS Class-AB Car Amplifier 4 Channel

Experience Unrivaled Audio Power and Precision: The ORION HCCA2000.4 HCCA Series 2000W RMS 4-Channel Class-AB Amplifier sets a new standard for audio excellence, delivering a perfect blend of power, precision, and efficiency. Crafted for audiophiles who demand the ultimate in sound quality, this amplifier elevates your audio experience to extraordinary heights.

Elevate Your Audio Journey: Elevate your audio experience with the ORION HCCA2000.4 HCCA Series 2000W RMS 4-Channel Class-AB Amplifier. Expertly crafted and featuring advanced capabilities, this amplifier transforms your listening into an immersive sonic adventure.

Uncompromising Sound Fidelity: Rediscover your music with unmatched clarity and detail. From gentle melodies to powerful crescendos, every sonic element is faithfully reproduced.

Unparalleled Power and Precision: Experience a perfect marriage of power and precision that redefines your audio landscape. The ORION HCCA2000.4 HCCA Series Amplifier seamlessly merges commanding power with sonic accuracy, creating a listening journey that captivates the senses.

Elevate Your Drive: Elevate your driving experience with the ORION HCCA2000.4 HCCA Series 2000W RMS 4-Channel Class-AB Amplifier. Elevate your audio journey and embrace a level of sonic excellence that sets new benchmarks.

Key Features

• Class-AB Amplification: Experience the harmonious blend of Class-AB amplification, combining the efficiency of Class B with the sound quality of Class A for an unparalleled sonic journey.
• 2000 Watts RMS: Immerse yourself in a world of commanding audio power with 2000 Watts RMS, delivering impactful and dynamic sound performance.
• Precision Audio Control: The adjustable built-in crossover allows meticulous calibration of audio frequencies, optimizing speaker performance.
• Customized Bass Enhancement: Elevate your low frequencies with the adjustable bass boost feature, delivering impactful and resonant bass notes.
• Advanced Protection Measures: Equipped with protection circuitry, the amplifier safeguards against overheating and short circuits, ensuring lasting reliability.
• Compact and Stylish Design: The amplifier's sleek design seamlessly integrates into your audio setup, adding a touch of sophistication without compromising performance.
• Engineered Excellence: Meticulously engineered for optimal audio precision, power efficiency, and unwavering performance.
• All MOSFET Power Supply
• Remote Gain Control
• Heavy Gauge Direct-Wire High Current Power and Speaker Terminals
• Electronic Crossover Network
• Bass Boost Circuitry
• Tri-Mode Capable
• High-Pass/Low-Pass Filter Control
• Power and Protection LED Indicators
• Soft Turn-on/Turn-off
• Balanced Input (CMRR)
• Fault and Protection Monitoring
• 4-Way Protection: Thermal, DC offset, Short Protection, under & over voltage

Power Rating

• - RMS WATTS @ 4 Ohms @ 0.5% THD+N: 4 x 300W
• - RMS WATTS @ 2 Ohms @ 0.5% THD+N: 4 x 500W
• - RMS WATTS @ 4 Ohms @ 0.5% THD+N: 2 x 1000W
• POWER TERMINAL MANAGEMENT
• Positive Terminals: 1 x 0 AWG.
• Negative Terminals: 1 x 4 AWG.
• Remote Turn-ON Signal: 10 AWG.
• Speaker Output Terminals: 10 AWG.

Specifications

• - Frequency Response 10Hz to 35kHz +/- 1 dB
• - Linear Bandwidth 20Hz to 65kHz +/- 3 dB
• - High Pass Crossover Continuously variable (40-1.25kHz/400-12.5kHz)
• - Low Pass Crossover Continuously variable (40-300Hz)
• - Phase shift control 0 to 180
• - Bass Boost 0-18dB variable
• - Distortion at Rated Power 0.005% THD+N
• - Damping Factor > 100
• - Input Sensitivity(RMS) 200mV to 6V
• - Supply Voltage Range 9 to 16V
• - Input Impedance 20K Ohms
• - Amplifier Efficiency > 67% into 2 Ohms load at max. power
• - SNR at rated output power and lowest impedance > 95dB
• - Fuses: 200A recommended (not included)
• - Dimensions (L x W x H): 20.47" x 11.89" x 3.15" (520x302x80mm)
