Orion HCCA151SPLX - 15 Inch Dual 1 Ohm Extreme SPL Subwoofer | 7500W RMS Bass Power

Extreme SPLX 15 Inch Subwoofer Built for Record-Level Output

The Orion HCCA151SPLX sits at the absolute peak of Orion's bass lineup. Specifically, this 15 inch dual 1 ohm SPLX competition subwoofer is engineered for extreme sound pressure levels. As a result, it delivers crushing low-frequency output for the most demanding SPL builds. With 7500W RMS and 30000W peak power, it is built for competitors who operate far beyond standard limits.

Additionally, the dual 1-ohm voice coil configuration allows ultra-low impedance wiring. Because of this, the subwoofer pairs perfectly with high-voltage, competition-grade amplifiers. Therefore, the HCCA151SPLX is ideal for extreme SPL competition vehicles, demo monsters, and record-chasing bass walls.

Built for Extreme SPLX Abuse

To survive brutal power levels, the HCCA151SPLX uses a moisture- and UV-resistant glass fiber paper cone. Moreover, it features a reinforced NBR foam surround designed to handle violent cone movement. Together, these components maintain stability during massive excursion.

At its core, the subwoofer uses a huge 4-inch high-temperature voice coil. As a result, it manages intense heat during long competition runs. In addition, a 690 oz triple-stack ceramic magnet motor structure delivers enormous motor force. This design maximizes output while maintaining control at extreme power levels.

Ideal For

• Extreme SPLX competition vehicles
• Record-focused bass builds
• Multi-subwoofer bass walls
• High-voltage, ultra-high-power audio systems

Key Features

• 15 inch dual 1 ohm extreme SPL subwoofer
• 7500W RMS / 30000W peak power handling
• Massive 4" high-temperature voice coil
• Glass fiber reinforced paper cone for extreme strength
• Reinforced NBR foam surround for violent excursion
• Polypropylene dustcap for added cone stability
• Huge 690 oz triple-stack ceramic magnet
• Designed specifically for SPLX-level output
• Optimized for extreme competition-style enclosures
• Legendary Orion Car Audio HCCA SPLX Series engineering

Key Features

• Extreme Competition Power: The Orion HCCA151SPLX Subwoofer is engineered for maximum performance, boasting an incredible RMS power handling of 7,500 watts and a peak power capacity of 30,000 watts, perfect for handling the most extreme power levels in competitive settings.
• Dual 1-Ohm DVC Configuration: The Orion HCCA151SPLX Subwoofer features a dual 1-ohm DVC (Dual Voice Coil) setup, providing versatile wiring options to optimize impedance and deliver maximum power output.
• Precision Sound Reproduction: The Orion HCCA151SPLX Subwoofer utilizes a non-pressed paper cone and NBR rubber surround to deliver precise sound reproduction, effectively managing extreme power levels while maintaining exceptional audio clarity and accuracy.
• Exceptional Performance: Featuring a robust 4-inch voice coil, the Orion HCCA151SPLX Subwoofer is designed to perform flawlessly under the most demanding audio conditions, making it the perfect choice for competitive setups and serious audiophiles.
• High-Quality Components: The Orion HCCA151SPLX Subwoofer is crafted with a premium magnet structure, advanced cooling technology, and durable materials, ensuring reliable, consistent performance even during prolonged, high-power use.

Specifications

• Subwoofer Size: 15" (Inches)
• Voice Coil Configuration: Dual 1-ohm
• Power Handling (Peak): 30000 Watts
• Power Handling (RMS): 7500 Watts
• Sensitivity: 87.81 dB
• Frequency Response: 20 Hz - 200 Hz
• Voice Coil Diameter: 4" (Inches)
• Dustcap Material: Polypropylene
• Cone Material: Moisture and UV Resistant Glass Fiber Paper Cone
• Surround Material: NBR Foam
• Magnet Information: 690 Oz Triple Stack Ceramic
• Mounting Depth: 379.5mm / 14.94 (Inches)
• Cutout Diameter: 383mm / 15.08 (Inches)
• Overall Diameter: 423.5mm / 16.67 (Inches)
