All power ratings are figured using an electronic high pass crossover with a minimum crossover point of 150Hz at 24dB/Octave, 200Hz at 18dB/Octave, or 250Hz at 12dB/Octave.
Fs 158.735 Hz Qms 8.21 Vas 3.825 l Cms 0.14 mm/N Mms 7.204 g Rms 0.872 kg/s Dia 133 mm Sd 138.9 cm² Qes 0.565 Re 2.80 ohm Le mH Bl 5.969 Tm Qts 0.528 no 2.620 % SPL 96.2 dB
Frame Outer Diameter 6 13/16" (173.5mm) Motor Outer Diameter 3 9/16" (90mm) Tweeter Protrusion 13/16" (20.32mm) Mounting Hole Diameter 5 11/16" (145mm) Mounting Depth 3 5/32" (80mm)
