ADMP400.4
In Store Pick Up OnlyHighlights Full Range Class D Discrete Hi-Fidelity Design Click-in-Place Crossover Controls Band Pass...
- $499.00
- $499.00
- Unit price
- per
Subtotal:
$499.00
Couldn't load pickup availability
In Store Pick Up Only
Highlights
- Full Range Class D
- Discrete Hi-Fidelity Design
- Click-in-Place Crossover Controls
- Band Pass Capable
- Engineered in the USA
Description
Description
The Premium Series amplifiers are engineered in the USA with superior full-range Class D technology that surpasses the expectations of the most critical listener. Once heard, you will not believe the clarity and volume is coming from such a compact package.
Premium and Mini Premium amplifiers has been designed from the ground up by the renowned Stephen Mantz of ZED Audio. Stephen's four decades of experience designing amplifiers position him as one the most experienced mobile electronics engineer in the industry. These amplifiers feature a discrete Class D circuit for hi-fidelity sound quality, ultra flexible preamp capable of any active crossover situation, click in place crossover potentiometers for accurate crossover frequency selection, and the most efficient power supply which demands less on your electrical system.
| Continuous Power | 80W x 4 @ 4 ohms |
| At 14.4V Supply Voltage | 110W x 4 @ 2 ohms |
| Bridged | 220W x 2 @ 4 ohms |
| Frequency Response | 10Hz - 35KHz |
| Input Sensitivity (Unbalanced) | 0.2V to 8V |
| Input Sensitivity (Balanced) | 0.5V to 16V |
| Fuse Ratings | 20A @ 4 ohms / 30A @ 2 ohms |
| Filter Modes | High Pass - Low Pass - Band Pass |
| High Pass Filter @ 12dB/Oct | Ch 1+2: 55Hz - 4KHz |
| Linkwitz-Riley | Ch 3+4: 10Hz - 1KHz |
| Low Pass Filter @ 12dB/Oct | Ch 1+2: N/A |
| Linkwitz-Riley | Ch 3+4: 55Hz - 4KHz |
| Detented Filter Potentiometers | 41 Click-in-Place Frequencies |
| Remote Level Control | Included |
| Channel Input Mode Switch | No |
| Height | 1.96 in / 49.9 mm |
| Width | 5.94 in / 151 mm |
| Length | 8.26 in / 209.85 mm |
| Net Weight | 4.4 lb / 2.0 kg |
