All power ratings are figured using an electronic high pass crossover with a minimum crossover point of 60Hz at 24dB/Octave, 80Hz at 18dB/Octave, or 100Hz at 12dB/Octave.
Audio Dynamics speakers were designed to reproduce music with ultimate accuracy.
We've spent countless listening hours examining the tonal qualities of many different cone materials; from glass fiber, to Kevlar, to carbon fiber and more. Ultimately, we chose a paper cone for its ability to deliver astonishing realism and detailed timbre across the harmonics.
Our 1000 series speakers will pull you into the musical performance and breath new life into your music collection.
Fs 74.660 Hz Qms 7.461 Vas 14.480 Liters Cms 0.249 mm/N Mms 18.230 g Rms 1.147 kg/s Dia 160.900 mm/N Sd 202.351 mm^2 Qes 1.694 Re 3.213 Ohms Le 0.472 mH Z 3.856 Ohms BL 4.027 Tm Bl²/Re 5.047 N^2/W Qts 1.381 no 0.343 % SPL 87.500 dB EBP 44.073
Frame Outer Diameter 6 3/8" x 9 5/16" (165mm x 236mm) Grille Outer Diameter 7 3/16" x 10 3/16" (183mm x 258mm) Motor Outer Diameter 3 9/16" (90mm) Grille Protrusion 1 1/8" (28mm) Mounting Depth 3 1/16" (78.5mm)
