1000 Series 4" - CX414
In Store Pick Up OnlyHighlights Coated paper cone 4" (100 mm) Steel frame mid/woofer Lightweight foam surround...
- $99.00
- $99.00
- Unit price
- per
Subtotal:
$99.00
Couldn't load pickup availability
In Store Pick Up Only
Highlights
- Coated paper cone
- 4" (100 mm) Steel frame mid/woofer
- Lightweight foam surround
- 1" (25 mm) voice coil mid/woofer
- 1/2" (13 mm) polymer film tweeter
- 75 Watts RMS power handling*
- 4 ohm
All power ratings are figured using an electronic high pass crossover with a minimum crossover point of 90Hz at 24dB/Octave, 110Hz at 18dB/Octave, or 130Hz at 12dB/Octave.
Description
Description
Audio Dynamics speakers were designed to reproduce music with ultimate accuracy.
Our goal for this speaker was to produce the best sounding speaker for its affordable price point. Ultimately, we chose a coated paper cone to deliver great tonality and kept the cone and surround lightweight to maintain efficiency. This speaker sounds great and gets loud in low power systems.
Fs 86.81 Hz Qms 10.63 Vas 2.196 l Cms 0.677 mm/N Mms 4.968 g Rms kg/s Dia 78.24 mm Sd cm² Qes 1.441 Re 3.2 ohm Le 0.1967 mH Z 26.79 ohm Bl 2.453 Tm Bl²/Re N²/W Qts 1.269 no % SPL 81.88dB
Frame Outer Diameter 3 15/16" (99mm) Grille Outer Diameter 5 11/16" (144mm) Motor Outer Diameter 2 3/8" (60mm) Tweeter Protrusion 1/4" (6mm) Grille Protrusion 3/4" (19mm) Mounting Hole Diameter 3 1/2" (89mm) Mounting Depth 1 7/8" (47mm)
