AD2312 D2
In Store Pick Up OnlyHighlights Dual 2 ohm 12" Subwoofer 200W - 600W optimal power range 2.5"...
- $269.00
- $269.00
- Unit price
- per
Subtotal:
$269.00
Couldn't load pickup availability
In Store Pick Up Only
Highlights
- Dual 2 ohm 12" Subwoofer
- 200W - 600W optimal power range
- 2.5" voice coil diameter
- Designed for use in vented enclosures.
- Engineered in the USA.
- Also available in dual 4 ohm
Description
Description
The 2200 series 12" employs a finely-tuned balance of damping and motor force to achieve high efficiency, offering exceptional versatility and performance in a variety of real-world functions:
Fs 35.26 Hz Qms 6.299 Vas 21.52 l Cms 0.061 mm/N Mms 336.0 g Rms kg/s Dia 253 mm Sd cm² Qes 0.547 Re 3.877 ohm Le 2.989 mH Bl 23 Tm Qts 0.5033 no 0.1645 % SPL 84.26 dB EBP 64.46 Nominal Diameter 12 in Overall Diameter 12.45 in / 316 mm Mounting Hole Diameter 11 in / 279 mm Bolt Hole Circle DiameterMotor Outer Diameter 6.30 in / 160 mm Mounting Depth 6.30 in / 160 mm Required Pole Vent ClearanceDriver Displacement 0.136 cu ft / 3.87 l Minimum Sealed Volume N/A Minimum Vented Volume 1.32 cu ft / 38 l net* * Tune for desired response
The above designs have been engineered for a "two tier" balance of compatibility: First, between the cabin acoustics of a sedan, hatchback and an SUV, and second, between the two available voice coil configurations, for a total of six balance points. This ensures a linear response and optimal power handling for listening purposes under most circumstances. Please visit our Enclosure Design Service page for custom designs.
