Fs 64.4 Hz Qms 8.125 Vas 1.576 l Cms 0.058 mm/N Mms 105.1 g Rms 5.234 kg/s Dia 133.0 mm Sd 138.2 cm² Qes 0.627 Re 3.607 ohm Le 2.551 mH Z 50.35 ohm Bl 15.64 Tm Qts 0.582 no 0.0647 % SPL 80.26 dB EBP 102.71 Nominal Diameter 6.5 in Overall Diameter 7.13 in / 181 mm Mounting Hole Diameter 6 in / 152 mm Bolt Hole Circle DiameterMotor Outer Diameter 5.94 in / 151 mm Mounting Depth 4.52 in / 115 mm Required Pole Vent ClearanceDriver Displacement 0.041 cu ft / 1.18 l Minimum Sealed Volume N/A Minimum Vented Volume 0.25 - 0.50 cu.ft. Tune @ 40Hz * Tune for desired response
Please visit our Enclosure Design Service page for custom designs.
