Fs 58.780 Hz Qms 6.509 Vas 2.176 l Cms 0.074 mm/N Mms 96.970 g Rms 5.562 kg/s Dia 135.000 mm Sd 143.138 cm² Qes 0.892 Re 7.097 ohm Le 2.396 mH Z 8.516 ohm Bl 16.880 Tm Bl²/Re 40.149 N²/W Qts 0.784 no 0.047 % SPL 78.938 dB EBP 65.896 Nominal Diameter 6.5 in Overall Diameter 7.16 in / 182 mm Mounting Hole Diameter 6 in / 152 mm Bolt Hole Circle DiameterMotor Outer Diameter 5.74 in / 146 mm Mounting Depth 4.72 in / 120 mm Required Pole Vent ClearanceDriver Displacement 0.041 cu ft / 1.18 l Minimum Sealed Volume N/A Minimum Vented Volume 0.25 cu.ft. * Tune for desired response


Please visit our Enclosure Design Service page for custom designs.
