AD2510 D2
In Store Pick Up OnlyHighlights 300W - 600W optimal power range Dual 2 ohm voice coil 2.5...
- $249.00
- $249.00
- Unit price
- per
Subtotal:
$249.00
Couldn't load pickup availability
In Store Pick Up Only
Highlights
- 300W - 600W optimal power range
- Dual 2 ohm voice coil
- 2.5 inch Copper voice coil
- 160oz motor
- +/- 10mm Xmax
- Double high current tinsel leads
- PC spider
- Designed for use in vented enclosures.
- Engineered in the USA.
- Also available in D2
Description
Description
The 2500 series 10 employs a finely-tuned balance of damping and extensive motor force to achieve very high efficiency, offering exceptional versatility and unmatched performance in a variety of real-world functions.
Fs 38.66 Hz
Qms 4.971
Vas 17.22 liters
Cms 0.102 mm/N
Mms 165.5 g
Rms 8.119 kg/s
Dia 209.5 mm
Sd 344.8 sq cm
Qes 0.6583
Re 3.646 ohms
Le 3.114 mH
Z 31.18 ohms
BL 23.84 Tm
BL^2/Re N^2/W
Qts 0.5813
no %
SPL 83.8 dB
EBP
X-max +/- 10mm
Nominal Diameter 10in
Overall Diameter 10.845in / 275mm
Mounting Hole Diameter 9.33in / 237mm
Bolt Hole Circle Diameter
Motor Outer Diameter 6.29in / 160mm
Mounting Depth 3.862in / 98mm
Required Pole Vent Clearance
Driver Displacement 0.049 cu ft / 1.392 l
Sealed Volume 0.50 - 0.60 cu.ft.
Vented Volume 0.60 - 1.25 cu.ft. net
* Tune for desired response
Vehicle body style specific enclosure designs coming soon
The above designs have been engineered for a particular vehicle body style. The cabin acoustics of a sedan, hatchback, SUV, and under seat truck placement were part of the formula to ensure a linear response and optimal power handling for listening purposes under most circumstances. Please visit our Enclosure Design Service page for one off custom designs.
