AD1412 D4
In Store Pick Up OnlyHighlights 75W - 300W optimal power range Designed for use in moderate size...
- $169.00
- $169.00
- Unit price
- per
Subtotal:
$169.00
Couldn't load pickup availability
In Store Pick Up Only
Highlights
- 75W - 300W optimal power range
- Designed for use in moderate size sealed and vented enclosures and infinite baffle
- Engineered in the USA.
Description
Description
The 1400 series 12 is optimized for linear performance and versatility in medium size sealed and vented enclosures and infinite baffle alignments.
Fs 44.140 Hz Qms 6.295 Vas 39.860 l Cms 0.115 mm/N Mms 112.200 g Rms 4.997 kg/s Dia 251.000 mm Sd 494.809 cm² Qes 0.870 Re 7.175 ohm Le 1.774 mH Z 8.610 ohm Bl 16.021 Tm Bl²/Re 35.771 N²/W Qts 0.764 no 0.380 % SPL 87.944 dB EBP 50.741 Nominal Diameter 12in Overall Diameter 12.36in / 314mm Mounting Hole Diameter 11in / 279mm Bolt Hole Circle DiameterMotor Outer DiameterMounting Depth 5.39in / 137mm Required Pole Vent ClearanceDriver Displacement 0.06 cu ft / 1.78l Minimum Sealed Volume 1.25 cu ft / 35l net Minimum Vented Volume 2.00 cu ft / 56l net* Infinite Baffle Approved * Tune for desired response
Single trunk enclosure:
Dual trunk enclosure:
Single SUV enclosure:
Dual SUV enclosure:
Single truck enclosure:
Dual truck enclosure:
The above designs have been engineered for a "two tier" balance of compatibility: First, between the cabin acoustics of a sedan, hatchback and an SUV, and second, between the two available voice coil configurations, for a total of six balance points. This ensures a linear response and optimal power handling for listening purposes under most circumstances. Please visit our Enclosure Design Service page for custom designs.
