1210 - 1000 Series 10" Shallow Subwoofer
In Store Pick Up OnlyHighlights 10" Shallow Subwoofer Available in Single and Dual 4ohm 100W - 300W...
- $159.00
- $159.00
- Unit price
- per
Subtotal:
$159.00
Couldn't load pickup availability
In Store Pick Up Only
Highlights
- 10" Shallow Subwoofer
- Available in Single and Dual 4ohm
- 100W - 300W optimal power range
- 2" voice coil diameter
- Designed for use in small sealed & vented enclosures.
- Engineered in the USA.
Description
Description
The 1200 series 10" is optimized for linear performance and versatility in small to medium size sealed and vented enclosures with mounting depth of only 3.81". It performs well in 4th and 6th order bass-reflex arrangements, achieving virtually any desired response shape.
Single 4ohm Fs 29.470 Hz Qms 4.130 Vas 42.010 l Cms 0.280 mm/N Mms 105.590 g Rms 4.730 kg/s Xmax 15 mm (One-Way) Dia 204.140 mm Sd 327.300 cm² Qes 0.650 Re 3.200 ohm Le 1.500 mH Z 3.840 ohm Bl 9.830 Tm Bl²/Re 30.200 N²/W Qts 0.560 no 0.160 % SPL 84.190 dB EBP 45.520 Dual 4ohmFs 33.404 Hz Qms 3.206 Vas 33.901 l Cms 0.223 mm/N Mms 101.867 g Rms 6.667 kg/s Xmax 15 mm (One-Way) Dia 204.123 mm Sd 330.000 cm² Qes 0.765 Re 7.600 ohm Le 1.500 mH Z 9.120 ohm Bl 14.571 Tm Bl²/Re 27.936 N²/W Qts 0.618 no 0.159 % SPL 84.166 dB EBP 43.648 Nominal Diameter 10.0in Overall Diameter 10.35in / 263mm Mounting Hole Diameter 9.25in / 235mm Motor Outer Diameter 5.11in / 130mm Mounting Depth 3.81in / 97mm Driver Displacement 0.04 cu ft / 1.2l Minimum Sealed Volume 0.6 cu ft / 17l net Minimum Vented Volume 1.05 cu ft / 30l net* * Tune for desired response
The above designs have been engineered for a "two tier" balance of compatibility: First, between the cabin acoustics of a sedan, hatchback and an SUV, and second, between the two available voice coil configurations, for a total of six balance points. This ensures a linear response and optimal power handling for listening purposes under most circumstances. Please visit our Enclosure Design Service page for custom designs.
