6.5" Sealed Back Mid-High Pro Audio Line Array (LA) Loudspeaker | 300W RMS 8-Ohm
6.5" Sealed Back Mid-High Pro Audio Line Array (LA) Loudspeaker | 300W RMS 8-Ohm
Product Overview
6.5" Sealed Back Mid-High Pro Audio Loudspeaker | 300W RMS | 8 Ohm
DS18’s 6PRO600SE-8 is a 6.5” sealed-back mid-high pro loudspeaker engineered for vocal clarity and raw projection. Designed for systems that live in the upper registers and need to cut through ANY mix!
Engineered for LOUD
With 300W RMS / 600W MAX, an 8-ohm impedance, and 96dB sensitivity, this beast delivers high-output vocals and upper midrange with punch. The sealed-back design gives you more enclosure flexibility—perfect for install in tight spaces, doors, or prefab boxes without rear venting. Recommended for Dome and Diffuser Horn
Real-World Toughness
The 6PRO600SE-8 is rugged where it counts. A 2” fiberglass voice coil, CCAW windings, and a steel basket combine for the kind of detail and warmth that makes audio hit just right.
You Like It LOUD? Prove It With DS18’s 6PRO600SE-8!
Key Features
- Sealed-back design
- 300W RMS / 600W MAX
- 96dB sensitivity
- 2" fiberglass voice coil with CCAW windings
- Rugged steel basket
- Recommended for dome and diffuser horn
Specifications
| SKU | 6PRO600SE-8 |
|---|---|
| Nominal Diameter | 6.5" / 165mm |
| Nominal Impedance | 8 Ohms |
| RMS Power Handling | 300W |
| MAX Power Handling | 600W |
| Sensitivity (1w/1m) | 96dB |
| Frequency Response | 250Hz-12.5KHz |
| Recommended HI Pass Crossover | 320Hz |
| Sold in Pair or Single | Single |
| Grill Included | No |
| Demodulating Rings | Copper Ring |
| Cone Shape | Curvilinear |
| Speaker Terminals | Spade |
| Voice Coil Diameter | 2" / 50.6mm |
| Voice Coil Former Material | Fiberglass |
| Winding Material | CCAW |
| Cone Material | Paper |
| Dust Cap Material | Paper |
| Surround Material | Cloth |
| Basket Material | Steel |
| Basket Color/Finish | Black |
| Magnet Material | Ferrite |
| Magnet Weight | 45 Oz |
| Displacement Volume | 1.26L / 0.044ft3 |
| Equivalent Volume | 0.48L / 0.0171ft3 |
| Excursion (one way) | 1.2mm |
| Free Air Resonance | 490Hz |
| Mechanical Factor | 8.49 |
| Electrical Factor | 2.4 |
| Total Factor | 1.87 |
| Mechanical Mass | 18.165g |
| Mechanical Compliance | 0.018mm/N |
| BL Factor | 6.457 |
| Voice Coil Inductance | 0.1317mH |
| Cone Area | 138.93cm3 |
| DC Resistance | 5.2 Ohms |
| Overall Diameter | 6.54" / 166.2mm |
| Overall Depth | 2.83" / 71.8mm |
| Front Mount Baffle Cutout | 5.68" / 144.3mm |
| Mounting Depth | 2.6" / 66mm |
| Motor Diameter | 5.5" / 140mm |
