2-Channel High-to-Low Level Line Output Converter with Remote Turn-On
2-Channel High-to-Low Level Line Output Converter with Remote Turn-On
Product Overview
2-Channel High-to-Low Level Line Output Converter with Remote Turn-On
DS18’s MTLOC2 converts 2-channel factory speaker-level outputs into clean RCA signals for aftermarket amplifiers. Its selectable 20V or 40V high-level input works in various OEM systems without triggering errors.
Automatic Power-Up
Equipped with auto turn-on via audio sensing, DC offset, or remote trigger, the MTLOC2 powers your amplifier instantly and hassle-free without manual wiring.
Durability and Size
Built with surface mount technology and housed in a rugged aluminum casing, the MTLOC2 offers noise rejection, thermal protection, and a compact design for easy installation.
Superior Audio Quality
Operating from 10Hz to 20kHz with less than 0.01% distortion, the MTLOC2 preserves your music’s clarity and detail.
Upgrade with the MTLOC2 and enjoy pristine audio!
Key Features
- 2-Channel High-to-Low Conversion
- 20V / 40V Input Select
- Auto Turn-On (Audio / DC / Remote)
- Aluminum Casing & Noise Rejection
- 10Hz–20kHz Frequency Range (<0.01% THD)
Specifications
| Maximum Speaker Level Input | Selectable 20 / 40V (100 / 400 W RMS) |
|---|---|
| Maximum Preamp Output | Up to 9V |
| Nominal Conversion Ratio | 4:1 |
| Frequency Response | 10Hz - 20kHz |
| Total Harmonic Distortion | 0.01% |
| Signal To Noise Ratio | >110dB |
| Input Impedance | 100 ohms |
| Output Impedance | 100 ohms |
| Power Draw | 50mA |
| Recommended Fuse Rating | 1A |
| Bass Boost | No |
| Auto Turn-On | Yes (Audio Sens / REM / DC) |
| Remote Output | Yes |
| Level Matching Controls | Yes |
| Dash Remote Level Control | No |
| Led Indicators | Power / Clip |
| Housing Material / Color | Aluminum / Black |
| Wiring Connector | 14ga Quick Connector |
| Ground Isolation | No |
| Step-Down Method | Transformer |
| Input Selector | No |
| Overall Length | 4.3" / 110mm |
| Overall Width | 2.75" / 70mm |
| Overall Height | 1.1" / 28mm |
