2" Throat Bolt on Driver 400 Watts 3" Titanium Vc 8-Ohm
2" Throat Bolt on Driver 400 Watts 3" Titanium Vc 8-Ohm
Product Overview
DS18 PRO-D2 2" Throat Bolt On Compression Driver 3" Titanium VC 800 Watts 8 ohm
Engineered and Designed in the US, the DS18 Compression Drivers with aluminum horns are the top of the line high frequency driver/tweeter/horns in the market. These bad boys deliver so much power that you'd think with one horn your whole sound system is ready to deploy for a major concert. Simply put, there are no compression drivers that can compare to the sophistication, beauty, and precision of these horns especially in the Pro Audio/Voceteo World.
Thanks to the demands of our customers, after months of relentless tests and experiments, our team of audio-experts perfected the PRO line. We are ecstatic to share with you the product of hard-work and non-stop innovating attitude! We are sure that you will love your Compression Driver as much as we do.
Technical Details
|
Key Features
- 2" Compression Driver
- RMS Power: 400 Watts(800 Watts Peak)
- Impedance: 8 Ohm ~ 109dB
- Ferrite Magnet
- Titanium Diaphragm
- Bolt On
Specifications
| SKU | PRO-D2 |
|---|---|
| Peak Power Handling | 800 Watts |
| Program Power Handling | 400 Watts |
| Sensitivity (1w/1m) | 109 dB |
| Frequency Response | 500Hz-18.5KHz |
| Nominal Impedance | 8 ohms |
| Throat Diameter | 2" |
| Recommended Hi Pass Crossover | 800Hz |
| Diaphragm Material | Titanium |
| Magnet Material | Ferrite |
| Magnet Weight | 65 oz |
| Gross Single Unit Weight | 2.75 kg |
| Single Unit Box Dimensions W x L x H | 145 x 140 x 75 mm |
| Quantity of Units in Master Carton | 6 PCS/ctn |
| Gross Master Carton Weight | 15.50 kg |
| Master Carton Dimensions W x L x H | 450 x 320 x 900 mm |
| Overall Diameter | 6.69" / 170mm |
| Overall Depth | 3.2" / 81.4mm |
| Product Weight | 11.5 lbs |
| Product Dimensions | 7.5 x 7 x 3.5 |
| M/C Weight | 11.5 lbs |
| M/C Dimensions | 15 x 15.75 x 4.75 |
| M/C QTY | 4 |
| Sold In | Piece |
