DS18 PRO-GM8.4 8" Mid-Range Loudspeaker 580 Watts 4-Ohm

Availability: Out of stock SKU: PRO-GM8.4
Regular price $41.95 Sale price $33.56

Notify me if back in stock

Enter your email address to be notified if the product becomes available again.

Product Overview

DS18 PRO-GM8.4 8" Mid-Range Loudspeaker 580 Watts 4-Ohm

Our newest PRO-GM rendition is an identical counterpart to our very popular PRO- GM8 except now we offer it in 4 ohms instead of 8 ohms the model PRO GM8.4. This monster midrange handles up to 190W RMS and 580W maximum power. A frequency range of 90hz to 10khz will ensure you get the most out of your frequency range, so you hit all your desired notes with ease. These speakers are a very good selection for someone who wants a little mid bass and very precise voice through their 8-inch speakers. These give amazing crescendos and very solid rock bottom notes. They come with non-pressed paper cones and steel pressed frames that hold a 30oz ferrite magnet. These are very solid speakers that will make even the most advanced audiophile smile.

Highlights

  • DS18's highly popular series of High Powered pro audio.
  • Great DS18 design of high durability parts including strong ferrite magnet, pressed paper cone, and CCA voice coils to get you maximum loudness with great sound quality.
  • These mids come with a solid cone design and are pure midrange speakers and will be greatly complemented with a not included tweeter.
Technical Details
                                                    PRO-GM8.4 Product Manual

Model: PRO-GM8.4
Type: Midrange Loudspeaker
Size: 8"
RMS Power: 190W
MAX Power: 580W
Frequency Response: 90Hz-10KHz
Impedance: 4 ohm
Sensitivity: 94dB
Materials
Surround: Cloth Surround
Frame: Steel
Cone: Paper
Magnet: Ferrite
Voice Coil Wire: Kapton
Diameters
Voice coil size: 1.5"
Magnet Size: 30 oz.
Mounting Depth: 3.22" (86mm)
Cut-Out Dimension: 7.2" (182mm)

Key Features

  • 8" Mid-Range
  • MAX Power: 580 Watts
  • RMS Power: 190 Watts
  • Impedance: 4-Ohm
  • Ferrite Magnet


Specifications

SKU PRO-GM8.4
Nominal Diameter 8" / 203.2mm
Nominal Impedance 4 Ohm
RMS Power Handling 190W
MAX Power Handling 580W
Sensitivity (1w/1m) 94dB
Frequency Response 80Hz-10KHz
Recommended HI Pass Crossover 120Hz
Pair or Single Single
Grill Included No
Voice Coil Diameter 1.5" / 38.1mm
Voice Coil Former Material Kapton
Winding Material CCAW
Cone Material Paper
Dust Cap Material Paper
Bullet Material / Color N/A
Surround Material Cloth
Basket Material Steel
Basket Color/Finish Matte Black
Magnet Material Ferrite
Magnet Weight 30 oz
Equivalent Volume (Vas) 22.53L / 0.79ft3
Excursion (one way) (Xmax) N/A
Free Air Resonance (Fs) 86Hz
Mechanical Factor (Qms) 10.462
Electrical Factor (Qes) 0.795
Total Factor (Qts) 0.739
Mechanical Mass (Mms) 9.685g
Mechanical Compliance (Cms) 0.351mm/N
BL Factor (BL) 4.71
Voice Coil Inductance (Le) 0.431mH
Cone Area (Sd) 213.82cm2
DC Resistance (Re) 3.3 ohm
Overall Diameter 8.26" / 210 mm
Overall Depth 3.46" / 88 mm
Front Mount Baffle Cutout 7.2" / 183 mm
Mounting Depth 3.22" / 82mm
Motor Diameter 4.72" / 120mm
Gross Single Unit Weight (lb) 5
Single Unit Box Dimensions W x L x H (Inches) 9 x 9 x 4
Quantity of Units in Master Carton 8
Gross Master Carton Weight (lb) 40
Master Carton Dimensions W x L x H (Inches) 18.5 x 18.5 x 8.8
