2" Throat Bolt-On Mid-Range Compression Driver 220W RMS 8-Ohm with 3.5" Polyester Voice Coil and Neodymium Magnet
2" Throat Bolt-On Mid-Range Compression Driver 220W RMS 8-Ohm with 3.5" Polyester Voice Coil and Neodymium Magnet
Product Overview
DS18 PRO-DRNMS
2" Mid-Range Compression Driver With 3.5" Polyester VC And Neodymium Magnet
DS18’s PRO-DRNMS is a breakthrough in professional sound systems. This 2-inch mid-range compression driver is engineered for unparalleled sound clarity and power. Refine your professional setup or curate a custom soundstage with the PRO-DRNMS and get superior performance thanks to its expert design.
Feel the force of a high-power audio driver handling 110W AES/ 220W Program Power/ 440W peak, ensuring robust sound without distortion, even at extreme levels. The use of a high-strength polyester diaphragm guarantees durability while delivering accurate tonal precision. The Kapton voice coil, configured at 8-ohm, enhances heat resistance and energy efficiency, setting the stage for unmatched audio fidelity.
The heart of this driver lies in its neodymium magnet technology. Compact yet potent, it promises lightweight performance with exceptional magnetic force, translating into LOUD and detailed audio reproduction. With an expansive frequency range from 250Hz to 12.5KHz, the PRO-DRNMS handles mid-range frequencies effortlessly, maintaining sound integrity across the spectrum.
Installation is optimized for ease with an M6 bolt pattern and compact dimensions that fit snugly into any setup without sacrificing performance. The driver’s remarkable sensitivity of 120dB ensures it stands out as one of the loudest in its class, while a recommended high-pass crossover at 600Hz protects it from undue strain.
Designed for audiophiles and professionals alike, DS18’s PRO-DRNMS embodies reliability and superior sound quality!
Key Features
- 2" Mid-Range Compression Driver
- RMS Power: 220 Watts(440 Watts Peak)
- Impedance: 8 Ohm ~ 120dB
- Neodymium Magnet - Polyester Diaphragm
- Bolt On
- Easily Repaired With The PRO-DRNMSVC
Specifications
| SKU | PRO-DRNMS |
|---|---|
| Throat Diameter | 2" / 50.8mm |
| Installation Type | Bolt-on |
| Nominal Impedance | 8 ohm |
| AES Power Handling | 110W |
| Program Power Handling | 220W |
| Peak Power Handling | 440W |
| Sensitivity (1w/1m) | 120dB |
| Frequency Response | 250Hz - 12.5KHz |
| Recommended Hi Pass Crossover | 600Hz |
| Mid-Driver Voice Coil Diameter | 3.5" / 90 mm |
| Voice Coil Former Material | Kapton |
| Winding Material | CCAR |
| Diaphragm Material | Polyester |
| Magnet Material | Neodymium |
| Overall Diameter | 5.2" / 132mm |
| Overall Depth | 2.7" / 69mm |
| Bolt Pattern | M6 - 4" / 102mm |
| Gross Single Unit Weight | 1.8 kgs |
| Single Unit Box Dimensions W x L x H | 170x168x93 mm |
| Quantity of Units in Master Carton | 8 |
| Gross Master Carton Weight | 14.5 kgs |
| Master Carton Dimensions W x L x H | 350x350x201 mm |
