PRO-DK 1" Compression Driver with 3.5" x 4.4" Wave Guide Horn | 360W Peak 8-Ohm, Ferrite Magnet
Product Overview DS18 PRO-DK175WG 3.5” x 4.4” Wave Guide Horn + 1” Compression Driver Kit (Ferrite Magnet)...
Vendor:
DS18
Manufacturer SKU
PRO-DK175WG
Availability:
In Stock
Product Type:
Compression Drivers & Horns
- $59.95
- $59.95
- Unit price
- per
Subtotal:
$59.95
Couldn't load pickup availability
Instructions:
View Instructions
10 in stock
Product Overview
DS18 PRO-DK175WG
3.5” x 4.4” Wave Guide Horn + 1” Compression Driver Kit (Ferrite Magnet)
The PRO-DK175WG is a compression driver and waveguide combo made to cut through all noise. Offering pinpoint detail at high volume: ideal for pro audio setups, competition systems, and extreme SPL builds.
Ferrite-Powered Punch
This driver uses a ferrite magnet and a 1.75” titanium voice coil to deliver clean, dynamic sound in the 1.5kHz to 20kHz range. Rated at 90W AES, 180W Program, 360W Peak power handling and 101dB sensitivity, the PRO-DK175WG brings volume without distortion.
Wide Coverage
The 3.5” x 4.4” horn guide cuts through all noise with surgical precision, while offering a 140° horizontal x 15° vertical spread.
Built to Last
The cast aluminum waveguide and ABS-backed construction provide long-lasting durability in harsh conditions.
Take over any venue with DS18’s PRO-DK175WG!
Key Features
- Extreme SPL Output - 90W AES, 180W Program, 360W Peak
- Cut-Through-the-Noise Clarity - Titanium diaphragm
- Wide-Throw Sound Control - 140° horizontal dispersion
- High-Efficiency - 101dB Sensitivity
- Perfect for Loud Setups
Specifications
| Nominal Impedance | 8 Ohms |
|---|---|
| AES Power Handling | 90W |
| Program Power Handling | 180W |
| Peak Power Handling | 360W |
| Sensitivity (1w/1m) With Horn | 101dB |
| Frequency Response | 1.5kHz - 20kHz |
| Recommended High-Pass Crossover | 2kHz |
| Voice Coil Diameter | 1.75" / 44.4mm |
| Voice Coil Former Material | KSV |
| Winding Material | CCAW |
| Diaphragm Material | Titanium |
| Magnet Material | Ferrite |
| VC Cover Material | ABS |
| Magnet Weight | 21.9 Oz |
| Motor Diameter | 4.5" / 115mm |
| Nominal Diameter | 3.5" x 4.4" / 89 x 111mm |
| Throat Diameter | 1" / 25.4mm |
| Sound Coverage | 140° H x 15° V |
| Body Material | Aluminum Cast |
| Color / Finish | Satin Black |
| Overall Diameter | 3.5" x 4.4" / 89 x 111mm |
| Overall Depth | 6.6" / 167mm |
| Mounting Depth | 6.4" / 162mm |
| Mounting Hole Cut-out | 1" x 4" / 25.4 x 101.6mm |
