2” Throat Bolt-On Compression Driver 320 Watts With 2” Titanium Voice Coil 8-Ohm
Product Overview DS18 PRO-D22Ti.8 2” Throat Bolt-On Compression Driver With 2” Titanium Voice Coil DS18’s PRO-D22Ti.8 is...
Vendor:
DS18
Manufacturer SKU
PRO-D22Ti.8
Availability:
In Stock
Product Type:
Compression Drivers & Horns
- $83.95
- $83.95
- Unit price
- per
Subtotal:
$83.95
Couldn't load pickup availability
Instructions:
View Instructions
10 in stock
Product Overview
DS18 PRO-D22Ti.8 2” Throat Bolt-On Compression Driver With 2” Titanium Voice Coil
DS18’s PRO-D22Ti.8 is the only choice for those who demand the best from their systems. Its 2" throat diameter ensures maximum sound projection so your music reaches every corner of the venue. The bolt-on installation type guarantees hassle-free setup so you can focus on getting LOUD!
With a nominal impedance of 8 Ohms and an AES power handling capability of 160W, DS18’s PRO-D22Ti.8 is built to integrate easily into the most demanding audio setups. Its program power handling of 320W and peak power handling of 640W ensure a dynamic and immersive listening experience.
Equipped with a 2" voice coil made from high-quality Titanium, this compression driver provides excellent heat resistance and durability, for years of reliable performance. The titanium diaphragm delivers crystal-clear highs with exceptional accuracy, allowing you to hear every detail in your music.
The PRO-D22Ti.8 features a robust ferrite magnet that enhances efficiency and magnet weight of 35 Oz for precise control over the sound output. The aluminum body not only adds durability but also contributes to reducing unwanted resonance for cleaner sound reproduction.
Upgrade with DS18’s PRO-D22Ti.8 2" and experience audio like never before.
Key Features
- 2" Compression Driver
- RMS Power: 320 Watts(640 Watts Peak)
- Impedance: 8 Ohm ~ 109dB
- Ferrite Magnet - Titanium Diaphragm
- Bolt On
- Easily Repaired With The PRO-D22Ti.8VC
Specifications
| SKU | PRO-D22TI.8 |
|---|---|
| Throat Diameter | 2" / 50.8mm |
| Installation Type | Bolt-On |
| Nominal Impedance | 8 Ohms |
| AES Power handling | 160W |
| Program Power Handling | 320W |
| Peak Power handling | 640W |
| Sensitivity (1w/1m) | 109dB |
| Frequency Response | 630Hz-20KHz |
| Recommended Hi Pass Crossover | 800Hz |
| Sold in Pair or Single | Single |
| Filter (Bass Blocker) | 10Uf/100V |
| Body Material | Aluminum |
| Body Color / Finish | Black / Machined |
| Voice Coil Diameter | 2" / 50.8mm |
| Voice Coil Former Material | Kapton |
| Winding Material | CCAW |
| Diaphragm Material | Titanium |
| Magnet Material | Ferrite |
| Magnet Weight | 35 oz |
| Overall Diameter | 5.31" / 135mm |
| Overall Depth | 2.08" / 53mm |
| Bolt Pattern/Type | 4xM6 - 4" /102mm |
