Rockford Fosgate replacement for 1998-2013 Harley-Davidson motorcycles. 3-inch full-color display with a 4-volt pre-amp output and, plug-and-play...
SKU: PMX-HD9813
Availability: Many In Stock
$659.99
$659.99
Please hurry! Only 0 left in stock
Subtotal: $659.99

Specifications

Free Shipping

Free standard shipping on orders over $99

Estimated to be delivered on 12/01/2022 - 15/10/2022.

Fitment: (1998–2020)
Overview:
1998-2013 Harley-Davidson direct replacement digital media receiver USB Input with 1.5A USB Charging A2DP and AVRCP Bluetooth Wireless Streaming 3′′ Full Color TFT Display with Day/Night Mode Pandora Internet Radio Control SiriusXM-Ready satellite radio (requires SXV300 tuner) Digital AM/FM tuner with presets Selectable HP/LP/AP Crossover with Selectable 12/24 dB/Octave Slope AUX Input Software updatable via USB Retains factory thumb control functionality Voltage gauge with Low voltage Warning 7-Band Graphic EQ + PEQ Plug and Play Installation with OEM electrical connectors Independent Subwoofer Level Control Compatible with PMX-BTUR Remote control Multi-region radio frequencies 2-Year Warranty *Antenna not included
Bullets:
  • ASâ„¢ D4329 UV Certified: Marine Grade standards ensure resistance to extreme environments. IPX4 Water Intrusion Rating: Protects from splashing water, no matter the direction. CISPR 25 Class 3 EMI Compliant: Vehicles, boats and internal combustion engines – Radio disturbance characteristics – Limits and methods of measurement for the protection of on-board receivers. IPX6 Water Intrusion Rated: Water projected in powerful jets from any direction shall have no harmful effects. Made for iPod/iPhone: This device supports the Apple "Made for iPod/iPhone" protocol. Pandora Internet Radio: Pandora (also known as Pandora Internet Radio) is a music streaming and automated music recommendation service. Bluetoothâ„¢ Audio Streaming: Wirelessly stream audio to your unit with any compatible Bluetooth device. USB Playback: This source unit supports playback from a USB device. SiriusXM Readyâ„¢: This radio is ready to accept SiriusXM programming. Element Readyâ„¢ | Motorcycle: All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.
Specifications:
  • Crossover: Sub-Out variable from 60 Hz - 120 Hz Channel Separation: RCA: > 50 dB High-Level: > 50 dB Output Power: CEA-2006 Power Rating 25W x 4 @ 4Ω RMS 50W x 4 @ 2Ω MAX ≤1.0% THD+N Signal-to-Noise Ratio: RCA 2V: > 85 dB High Level (CEA-2006): > 75 dB Max Wrms: > 80 dB RCA Output Voltage: Front: 4 V Max Rear: 4 V Max Sub: 4 V Max Idle Current: < 2 Amps Frequency Response: RCA: 20Hz - 20 kHz High-Level: 20Hz - 20 kHz Operating Voltage: 9.5 - 16 VDC THD+N: 4Ω: < 1.0 % Output Impedance: < 500Ω AM Tuner: Range: 530 - 1710 kHz Sensitivity: 40 dB Frequency Response: 45 to 2.4 kHz USB Version: 2 Bluetooth: 3.0+EDR A2DP 1.3 FM Tuner: Range: 87.9 - 107.9 MHz Sensitivity: 8 dB Frequency Response: 20 - 15 kHz Supported Media Formats: MP3 WMA Clock: Yes USB Output Current: 1.5A USB Capacity: 32 Gb max 255 Folders max 999 Songs max Format Win USB as FAT32 Format Mac USB as MS-DOS (FAT) Display Size:: Nominal Size: 3′′ Color TFT Resolution: 960 x 240 Brightness: 380 nits Contrast: 400 Pixels: 320 x 240 View Angle: 120 Shipping Weight: 4.75 Lbs. (2.15 Kg) Made for iPhone Models: iPhone XS Max iPhone XR iPhone 8 Plus iPhone 7 Plus iPhone SE iPhone 6s iPhone 6 iPhone 5c iPhone XS iPhone X iPhone 8 iPhone 7 iPhone 6s Plus iPhone 6 Plus iPhone 5s iPhone 5 Made for iPod Models: iPod touch (5th generation) iPod touch (6th generation) Dimensions (HxWxD) : Faceplate: 2.7′′ x 8.4′′ x 0.7′′ (68.4 mm x 213 mm x 17.1 mm) Chassis: 2.5′′ x 8.2′′ x 7.5′′ (63.5 mm x 209.3 mm x 191 mm)
