MICRO4V2 - MICROV2 Series 4-Channel Full Range Class D Amplifier

Discover exceptional sound quality in a compact design with Diamond Audio's MICROV2 series of amplifiers. Utilizing ultra-efficient full-range Class D topology, these amplifiers deliver impressive power despite their small size. The MICROV2 series also features advanced Rollback/Thermal protection, ensuring continuous and uninterrupted play without any risk of shutdown.

The installation possibilities are endless with the MICROV2 series! These amplifiers boast an ultra-compact, high-density aluminum alloy chassis, making them versatile and easy to fit in any setup. Balanced differential inputs ensure noise-free operation, while full-range digital Class D technology with Direct FET power MOSFET output stage guarantees top-notch performance.

With 12dB per octave adjustable crossovers, Diamond bass boost EQ (12dB @ 45Hz), and advanced rollback power circuitry to keep your amp cool, the MICROV2 series keeps your music playing smoothly. The selectable 3-option Auto Turn-On Mode circuit is designed to work with any OEM head unit, simplifying installation and making it more convenient.

When you need quality and performance in a small package, look no further than the MICROV2 series from Diamond Audio. Upgrade your audio system today and experience the perfect blend of power, efficiency, and flexibility.

Features

Specifications

Input Sensitivity: 0.2-10 Volt
Crossover Filter : 40-400Hz, 12dB Per Octave Slope
Frequency Response: 10-33KHz
Selectable X-Over: LPF / FLAT / HPF
Dimensions: 9.7" x 4.0" x 1.46" / 230.5 x 103 x 37.2 mm
