All power ratings are figured using an electronic high pass crossover with a minimum crossover point of 500 Hz at 24 dB/Octave, 750 Hz at 18 dB/Octave, or 1000 Hz at 12 dB/Octave.
Audio Dynamics speakers were designed to reproduce music with ultimate accuracy.
We've spent countless listening hours examining the tonal qualities of many different cone materials; from glass fiber, to Kevlar, to carbon fiber and more. Ultimately, we chose wool pulp for its ability to deliver astonishing realism and detailed timbre across the harmonics. We then added an acoustically-transparent chemical to help the soft parts resist moisture.
Our speakers will pull you into the musical performance and breath new life into your music collection.
Fs 254.100 Hz Qms 4.835 Vas 0.095 l Cms 0.292 mm/N Mms 1.327 g Rms 0.443 kg/s Dia 43.910 mm Sd 15.143 cm² Qes 1.715 Re 3.056 ohm Le 0.111 mH Z 3.667 ohm Bl 1.943 Tm Bl²/Re 1.235 N²/W Qts 1.266 no 0.088 % SPL 81.583 dB
Frame Outer Diameter 2 7/8" (73 mm) Motor Outer Diameter 1 15/16" (49 mm) Mounting Hole Diameter 2 3/16" (55 mm) Mounting Depth 1 1/4" (32 mm)
