3.5” Dashboard Loudspeaker with Neodymium Magnet | 100W RMS 4-Ohm
Product Overview
3.5” Dashboard Loudspeaker with Neodymium Magnet
The 35D200N-4 is a 3.5-inch dashboard loudspeaker designed for accurate audio reproduction in custom car audio setups. Its compact size makes it perfect for tight spaces without sacrificing sound quality.
Power Handling & Sensitivity
This speaker handles 100W RMS and 200W MAX, with an 87dB sensitivity rating. It covers a frequency response range of 120Hz to 20kHz, providing crisp highs and balanced mids for clear, detailed sound.
Durable, Lightweight Design
Built with a glass fiber + composite foam cone and dust cap with resin finish, the 35D200N-4 ensures excellent audio performance. The rubber cloth surround and aluminum basket offer added stability, while the neodymium magnet provides powerful magnetic force.
Installation Made Easy
With a mounting depth of just 1.4 inches and a cutout diameter of 2.9 inches, this speaker installs quickly in most factory or custom dashboard locations.
Upgrade to DS18’s 35D200N-4 and experience the difference of pro-level audio!
Key Features
- Compact 3.5" design fits tight dashboard spaces
- 100W RMS / 200W MAX power handling
- 120Hz–20kHz range for clear mids and highs
- Lightweight glass-fiber composite foam cone
- Compact, high-output neodymium magnet
- Durable aluminum basket
Specifications
| Nominal Diameter | 3.5" / 91.5mm |
|---|---|
| Nominal Impedance | 4 Ohms |
| RMS Power Handling | 100W |
| MAX Power Handling | 200W |
| Sensitivity (1w/1m) | 87dB |
| Frequency Response | 120Hz-20Khz |
| Recommended HI Pass Crossover | 160Hz |
| Sold in Pair or Single | Pair |
| Improved Heat Dissipation | Yes |
| Cone Shape | Conic |
| Speaker Terminals | Spade |
| Voice Coil Diameter | 1" / 25mm |
| Voice Coil Former Material | TIL |
| Winding Material | Copper Ribbon |
| Cone Material | Glass Fiber + Foam Composite with Resin Finish |
| Dust Cap Material | Glass Fiber + Foam Composite with Resin Finish |
| Surround Material | Cloth |
| Leads Connection Type | Direct to Coil |
| Basket Material | Aluminum |
| Basket Color/Finish | Black |
| Magnet Material | Neodymium |
| Magnet Weight | 1.4 Oz |
| Equivalent Volume | 0.32L / 0.084ft3 |
| Excursion (one way) | 2mm |
| Free Air Resonance | 180Hz |
| Mechanical Factor | 6.54 |
| Electrical Factor | 1.45 |
| Total Factor | 1.19 |
| Mechanical Mass | 3.284g |
| Mechanical Compliance | 0.183mm/N |
| BL Factor | 3.085 |
| Voice Coil Inductance | 0.038mH |
| Cone Area | 28.27cm2 |
| DC Resistance | 3.81 Ohms |
| Mechanical Mass w/o air | 3.096g |
| Overall Diameter | 3.6" / 91.5mm |
| Overall Depth | 1.61" / 41.1mm |
| Front Mount Baffle Cutout | 2.93" / 74.3mm |
| Mounting Depth | 1.42" / 36mm |
| Motor Diameter | 1.96" / 50mm |
